STATISTICS
All data concerning sales and the machine operations is
stored in both total counters and relative counters, which
can be reset without losing total data.
Printing
Connect an RS232 serial printer having a Baud rate of 9600,
8 data bit, no parity, 1 stop bit to the serial port located on
the push button board to print all of the statistics.
The printout will also contain the machine information, the
date and the software version.
To connect the printer, do as follows:
- press the confirm print button " ", displaying the message
"Confirm?";
- connect the printer before confirming;
- press the confirm button " " to start printing.
Displaying
Press the confirm button " " to display in a sequence the
same data obtained with the statistic printing, for both total
and relative counters.
Deleting
Statistics can be reset for relative counters globally (all
types of data) or selectively for:
- selections
- failures
- coin mechanism data
Press the confirm button " ", and the message "Confirm?"
starts blinking.
Press the confirm button " ", the message "Working" is
displayed for a few seconds and all statistics are reset.

SELECTION PRICES

This function is used for changing the sales price for each
single selection and for each time band that may be set.
FILL>
PRICES
© by N&W GLOBAL VENDING SpA

CHANGE TUBES CONTROL

By accessing the "Tube control" function the change tubes
can be filled or released manually.
Confirm refilling, and the display will indicate
"Credit: ——" which is the value of money available in
change the tubes; insert the desired coin into the validator
and the display will indicate the value of money available in
the change tubes.
When confirming releasing, it will be possible to decide
which tube to release. Each time the confirm button " " is
pressed, a coin is ejected from the active tube.
FILL>
FILL>
FILL>

DISPLAYING THE TEMPERATURE

With this function it is possible to read the boiler tempera-
ture directly in °C.
The symbol " " indicates that the boiler heating element is
not heating.
The symbol " " indicates that the boiler heating element is
heating.
FILL>
PRICES
Selection #
Selection #
Time band #
Time band #
Price # #. # #
18
Tubes control
Fill tubes
Credit:#####
Release tubes
Credit:#####
Boiler temperature
Release tubes
Tube A ÷ X
Boiler temperature
T. = ##,# °C
