Connect and Fasten Cell Cap
Slip the Cell Cap through the Retaining Nut as shown below. Plug the Cell Cap into the Cell and secure with the Retaining
Nut. Run pump for 5 minutes and check for leaks.
Retaining Nut
Cell Cap
Flow Switch Calibration Procedure
IMPORTANT: Before going any further, the pool water must be balanced and salt must be added to your pool. If this has
not already been done, refer to the "Water Chemistry" section of this manual for information on how to prepare your pool
water for Salt & Swim 3C operation.
At start-up, or when a new Cell is installed, the Salt & Swim 3C will run a Flow Switch Calibration procedure to ensure that
the Cell's flow switch is properly initialized. This will occur just once when a new Cell is installed. After the flow switch is
initialized, the Salt & Swim 3C will not perform this procedure again until the Cell is replaced. The Flow Switch Calibration
procedure will require the user to cycle the pump on and off. Follow the instructions below:
1. Turn the filter pump OFF.
2. Plug the Salt & Swim's linecord into a protected outlet. Follow Local and National codes.
120 V
Protected
outlet
After being powered on for the first time, the Salt & Swim 3C will run a diagnostic routine which can take up to 30
seconds. During this time, various LEDs will turn on and off. When finished, the Salt & Swim 3C will display a blinking
INADEQUATE WATER FLOW LED and a solid STANDING BY LED. Keep the Salt & Swim 3C powered for the remainder
of this procedure and go to Step 3.
