HPS10 PersonalScope TM
Use
USE
1
2
Survey of the connections and
!
controls
1. BNC input connector (max. input 100Vp
I/O
9V DC
AC+DC).
2. Adapter connection (observe the polarity!)
3. Battery compartment.
4. X10 probe testing signal behind battery cover.
Fig 7.0
5. Serial number.
4
5
3
Fig 8.0
16
