Right View; Description - Benelli IMPERIALE 400 Manuel Du Propriétaire

Right view

1) Front light.
2) Front position indicators.
3) Rear position indicators.
4) Footrests.
5) Battery compartment cover.
6) Rear-view mirrors.
7) Saddle.
8) Rear brake light.
9) Side stand.
10) Rear brake disc.
11) Shift pedal.
12) Fuel tank.
13) Exhaust manifolds.
14) Front brake disc.
15) Dashboard.
16) Engine oil inspection port.
17) Rear brake pedal.
18) Passenger pedals.
19) Fuel tank cap.
20) Switch.
21) Rear shock absorber.
22) Central stand.
