Connecting 3-Wire Connection: Optional
Use for direct wire or power supply cord where local codes do not
permit connecting cabinet-ground conductor to neutral wire.
Connecting Neutral Wire
1. Remove center terminal block screw. Also remove neutral
ground wire by removing external ground conductor screw.
2. Connect neutral wire and neutral wire of power supply cord/
cable to center terminal bloc
Leveling Stacked Washer/Dryer
Leveling your washer/dryer properly reduces excess noise and
vibration.
1. Remove cardboard from beneath washer/dryer. Place a level on
top edges of washer/dryer, checking each side and front. If not
level, tip washer/dryer and adjust feet up or down as shown in
Steps 3 and 4, repeating as necessary.
ELECTRIC DRYER ELECTRICAL CONNECTIONS
k.
3. Connect remaining wires to outer terminal block.
4. Connect a separate copper ground wire from the external
ground conductor to an adequate ground.
Not Level

LEVELING

LEVEL
Not Level
27
