Step 2
Insert the bracket on front stabilizer (2) into the front support (29). Unfold the front upright (3) onto the
front support (29), then bolt the front support (29), front upright (3) and front stabilizer (2) together
with bolts (M8 x 15mm) (14) and washers (M8) (16). Please do not tighten any of these bolts until all six
bolts are attached.



Step 3
Insert the pedal shaft (5) through holes located on the front upright (3). Place a pedal (4) onto each end
of the pedal shaft (5) and slide them toward the front upright (3). Then secure the pedals (4) with bolts
(M8 x 15mm) (14) and large washers (M8) (15) at both ends of the pedal shaft (5).
Note: you need to use two allen wrenches to tighten the bolts (M8 x 15mm) (14) at both ends of the
pedal shaft (5) at the same time.






22
