2.
Application
WAVE
CONTROL
10 A, and can be used for monitoring tasks in diverse areas.
All variables are configured via DIP switches. Further calibration is not
necessary. The measurement circuit is galvanically isolated. Measure-
ment results are available for further processing as an analog value.
The device is available with a pluggable screw connection or pluggable
tension clamp connection.
3.
Mounting and Settings
3.1
Range adjustments
1. Remove À connector.
2. Press locking clips  on both sides of the enclosure and pull out the
circuit board.
3. Make required adjustments to the input range and frequency using the
DIP switches.
4. Replace connector after making adjustments The connectors have
been coded by the manufacturer, ensuring that they cannot be re-
versed.
CAUTION
The circuit board can only be inserted in one position.
current-monitoring modules, measure AC currents up to
15
