3. INSTALLATION

Note:
All following descriptions refer to the A version of the
room ventilation unit.
For further information, please refer to the operating
and installation instructions of the room ventilation unit.
Risk of injury:
Before installing the bypass, disconnect all poles of
the room ventilation unit from the power supply
system, since injury may otherwise result.
2
3
1
1. Remove designer cover (1).
2. Unscrew screws (2) and remove front cover (3).
3. Unscrew the screws (4).
2
4. Fold the cover (5) upwards in service position.
M+P-26A-0925
4
4
5
II bypass for Avent P190/P310/P460
M+P-26A-0890
M+P-26A-0905
3
