Explosion protected empty enclosure made of stainless steel type Ex-Cell
1
Technical data
ATEX type examination certificate:
Marking acc. to 2014/34/EU and standard:
IECEx type examination certificate:
Marking:
Permissible service/operating temperature and storage temperature in original packaging: depending on sealing used:
Protection category acc EC/IEC 60529:
Insulation class to EN/IEC 61140:
Cable entries:
Test torques:
Cover screws
Mounting screws for flange plates
Enclosure sizes:
Baseefa 15 ATEX 0099U
EN 60079-0
IECEx BAS 15.0071U
IEC60079-0
Ex e IIC Gb
Ex tb IIIC Db
standard gasket
-40° C
flat gasket
-60° C
IP66
II
see section 6 and 10
4.0 Nm
2.0 Nm
width (B)
smallest
150 mm
biggest
1200 mm
dimensions
see section 10.1
II 2 G Ex e IIC Gb
II 2 D Ex tb IIIC Db
to
+80° C
to
+135° C
(catalogue version)
height (A)
150 mm
1600 mm
depth (C)
80 mm
400 mm
GB
9
