BURNER DESCRIPTION
Gas burner with two stage working.
CE marking according to Gas Appliance directive 90/396/EEC; PIN 0063AP6680.
According to directives: EMC 89/336/EEC, Low Voltage 73/23/EEC, Machines 98/37/EEC and
Efficiency 92/42/EEC.
Gas train according to EN 676.
2 - Air dampers
3 - Cable clamps
4 - Cable grommet
5 - Screw for fixing the cover
9 - Reset button with lock-out lamp
NOTES:
- The cable grommet (4) supplied with the burner, must be fitted to the same side of the gas train.
- After having installed the burner verify the access to the fixing screws of the cover.
If necessary replace them with the fixing screws (5, fig. 1) supplied as equipment.
1.1 BURNER EQUIPMENT
Insulating gasket . . . . . . . . . . . . . No. 1
Cable grommet . . . . . . . . . . . . . . No. 1
Hinge . . . . . . . . . . . . . . . . . . . . . . No. 1
2748
1
4.
WORKING . . . . . . . . . . . . . . . . . . . . . . .
1
2
2
2
2
3
3
5.
WARNINGS
4
to avoid burnout or bad combustion of the
burner . . . . . . . . . . . . . . . . . . . . . . . . . . .
4
6.
5
6
7.
9
8
7
6
5
4
Screws and nuts for flange to be fixed to boiler. . . No. 4
Screw for fixing the cover . . . . . . . . . . . . . . . . . . . No. 3
1
GB
Fig. 1
