Parts List - BH FITNESS BLADEZ MASTER GS Guide D'utilisation

To order replacement parts: provide your customer service representative with the product model number
and the part number located on the Parts List below, along with the quantity you require.
NO. DESCRIPTION
MasterGS-1 Main Frame
MasterGS-2 Seat Post
MasterGS-3 Seat Slider
MasterGS-4 Handlebar Post
MasterGS-5 Handlebar
MasterGS-6 Cap Nut
MasterGS-7 Rear Stabilizer
MasterGS-8 Front Stabilizer
MasterGS-9 Tension Knob
MasterGS-10 Tension Bracket welding
MasterGS-11 Plastic sleeve
MasterGS-12 R/L Crank
MasterGS-13 Phillips Self-Tapping Screw
MasterGS-14 Chain Cover A
MasterGS-15 Chain Cover B
MasterGS-16 Base Leveler
MasterGS-17 Plastic Sheath –Inner Pipe(long)
MasterGS-18 Stabilizer Cap
MasterGS-19 Seat Slider Cap
MasterGS-20 Front Cover
MasterGS-21 Pulley
MasterGS-22 Seat
MasterGS-23 Pop Pin
MasterGS-24 Leather Brake Pad
MasterGS-25 Brake Soft Mat
MasterGS-26 Plastic Mat – Chain Cover
MasterGS-27 Sheet Metal Screw Clip
MasterGS-28 Belt
MasterGS-29 Flat Washer
MasterGS-30 Axle Welding
MasterGS-31 Rubber washer
MasterGS-32 Crank Cover
MasterGS-33 Flat Washer
MasterGS-34 Button Hex Socket Head Screw
MasterGS-35 Right & Left Pedal
MasterGS-36 Flywheel
MasterGS-37 Flywheel Spindle
MasterGS-38 PK Belt wheel
MasterGS-39 Sleeve
MasterGS-40 Tension Spring
MasterGS-41 Pulley Flywheel-Front Drive
MasterGS-42 Brake Holder
MasterGS-43 Spring Slice
Register your product warranty online at: www.BHFitnessUSA.com
18
Questions regarding warranty and parts call: 636.634.2217

PARTS LIST

QTY. NO.
1 MasterGS-44
1 MasterGS-45
1 MasterGS-46
1 MasterGS-47
1 MasterGS-48
1 MasterGS-49
1 MasterGS-50
1 MasterGS-51
1 MasterGS-52
1 MasterGS-53
1 MasterGS-54
1 set MasterGS-55
8 MasterGS-56
1 MasterGS-57
1 MasterGS-58
4 MasterGS-59
1 MasterGS-60
4 MasterGS-61
1 MasterGS-62
1 MasterGS-63
2 MasterGS-64
1 MasterGS-65
1 MasterGS-66
1 MasterGS-67
1 MasterGS-68
2 MasterGS-69
1 MasterGS-70
1 MasterGS-71
1 MasterGS-72
1 MasterGS-73
1 MasterGS-74
2 MasterGS-75
4 MasterGS-76
4 MasterGS-77
1 set MasterGS-78
1 MasterGS-79
1 MasterGS-80
1 MasterGS-81
1 MasterGS-82
1 MasterGS-83
1 MasterGS-84
1 MasterGS-85
1 MasterGS-86
DESCRIPTION
Bearing 6001
Bearing 6004
Bearing 608
Brake Thread Rob
C-shaped Buckle
Hexagon Bolt
Inner Hexagon Hollow Bolt
Brake Adjusting Nut
Washer
Inner Hexagon Flange Bolt
Cross Recessed Countersunk Bolt
Hexagon Thin Bolt
C-shaped Buckle
Hexagon Flange Bolt
Nylon Nut
Cross Recessed Pan Head Bolt
Inner Hexagon Flat Round Head Bolt
Pedal House
String - Pedal
Plastic Sheath – Inner Pipe
Phillips Screws
Cap Nut
Handle
Flat Mat (bigger and thicker)
Outer Hexagon Bolt
Washer (Bigger)
Washer
Cap Nut
Phillips Screws
Inner Hexagon Flat Round Head Bolt
Washer
Inner Hexagon Flat Round Head Bolt
Inner Pipe Cap
Inner Screw Cap
Limited Bearing
Spring
Computer Console
Water Bottle Holder
Phillips Bolt
Up Sensor Line
Down Sensor Line
Magnet
Console Mount
QTY.
2
2
4
1
2
5
2
1
4
2
2
3
1
1
1
6
2
2
2
2
1
2
3
1
2
2
1
1
2
1
1
4
2
2
2
2
1
1
1
1
1
1
1
