STEP 1
ASSEMBLE FRONT AND REAR STABILIZERS
Detach the shipping supports (metal pieces attached with 2 screws) – under the front and
rear stabilizers. Discard the supports and screws.
Follow the figure below and attach the Front Stabilizer (8) and Rear Stabilizer (7) under the
Main Frame (1) with 4 pcs of Button Head Hex Socket Bolts (34),
4 pcs of Flat Washer (33) by using the supplied Allen wrench for fastening.
STEP 2
INSTALL LEFT AND RIGHT PEDALS
Refer to the figure on right, thread the Left
Pedal (35-L) and Right One (35-R) into the
Cranks. Tighten them with Open Wrench #15.
Tighten in counter clockwise direction for left
pedal and clockwise direction for right pedal.
