NOMENCLATURE
(PAGE 2)
1)
Infrared fl ash
2)
LED indicator
3)
PIR Motion Sensor
4)
Camera lens
5)
LCD display
6)
Menu button
7)
Arrow buttons (menu control)
8)
OK button
FIRST USE
1. Open the camera releasing the lateral tension locks (16).
2. Make sure that the On/O switch (9) is on OFF position.
CAUTION:
To avoid camera damages always make sure that camera is switched o (9=OFF) when inserting batteries
or changing SD card.
3. Insert 8 x AA/1,5V batteries into battery compartment. Respect correct polarity (+/-).
4. Insert a SD card with the label facing upwards into the SD card slot (12). Make sure that the SD card is unlocked.
5. Slide the On/O switch (9) to "SETUP" position. The Display shows the basic settings:
SETUP
In order to change the camera settings slide the On/O switch (9) to ""SETUP" position and press the "MENU" button (6).
The LCD display (5) shows a list of various menu options:
Camera Mode
MENU–Exit
OK–
Save
1. Press the arrow buttons (7) ƒor „ to switch between the registers (CAM, PIR, SYS).
2. Press the arrow buttons (7) ‚ or to select the menu point. The selected menu point is marked white.
3. Press the arrow buttons (7) ƒ or „ to change the menu point.
4. To save your settings press the the "OK" button (8). To leave setup without saving, press the "MENU" button (6).
Single picture mode
Camera symbol
5M
Resolution 5 Mega Pixels
Battery symbol
Battery status
[00034/00965]
Stored pictures/free capacity
9)
ON/OFF switch + Setup
10)
DC 6V connection
11)
Mini USB port
12)
SD card slot
13)
Battery compartment
14)
1/4" thread mount
15)
Eyelet for U-lock
16)
Tension locks
