03 | NOMENCLATURE (PAGE 2 - 3)
1 Infrared fl ash
2 LED indicator
3 PIR Motion Sensor
4 Camera lens
5 LCD display
6 Menu Button
04 |

FIRST USE

1. Open the camera releasing the lateral tension locks (16).
2. Make sure that the On/O switch (9) is on OFF position.
CAUTION
To avoid camera damages always make sure that camera is switched o (9=OFF) when inserting batteries or changing SD card.
3. Insert 8 x AA/1,5V batteries into battery compartment. Respect correct polarity (+/-).
CAUTION
Do not use re-chargeable batteries. They may lead to malfunction.
4. Insert a SD card with the label facing upwards into the SD card slot (12). Make sure that the SD card is unlocked and
formatted.
5. Slide the On/O switch (9) to "SETUP" position. The Display shows the basic settings:
05 | SETUP
Camera Mode
MENU–Exit OK–
Save
1. Press the arrow buttons (7)
2. Press the arrow buttons (7)
3. Press the arrow buttons (7)
4. To save your settings press the the "OK" button (8). To leave setup without saving, press the "MENU" button (6).
7 Arrow buttons (menu control)
8 OK button
9 ON/OFF switch + setup
10 DC 6V connection
11 Mini USB port
12 SD card slot
Camera symbol
5M (Factory setting)
Battery symbol
[00000/00000m]
In order to change the camera settings slide the On/OFF switch (9) to ""SETUP" position
and press the "MENU" button (6).The LCD display (5) shows a list of various menu options:
or to switch between the registers (CAM, PIR, SYS).
or to select the menu point. The selected menu point is marked white.
or to change the menu point.
13
14
15
16
Single picture mode
Resolution 5 Mega Pixels (3 MP / 5 MP / 8 MP selectable)
Battery status
Stored pictures/free capacity
16
Battery compartment
¼" thread mount
Eyelet for U-lock
Tension locks
