Dimplex RD 907 TS/LCD Instructions De Montage page 11

RD 907 TS/LCD, RD 909 TS/LCD, RD911 TS/LCD
8. Cable storage (see Fig. 1)
If the radiator is not required the supply cord should be
unplugged and be neatly coiled around the cable wrap
ensuring that the plug does not trail on the floor.
Do not use the appliance with the cord coiled!
9. Cleaning
Switch off the appliance first and disconnect the
plug from the socket!
Clean the housing with a moist cloth, vacuum
cleaner or brush.
Do not use any abrasive or caustic cleaning
agents!
Do not use any flammable cleaning agents e.g. pet-
rol or spirit for cleaning the appliance.
Never immerse the appliance in water!
Danger to life!
Air inlet and outlet area should be cleaned with a
vacuum cleaner regularly.
If the appliance is not used for extended periods, it
must be protected against excessive dust and dirt.
10. After sales service
All repairs must be referred to authorised personnel!
See your local dealer. Any tampering with the appli-
ance will invalidate the warranty.
Repairs carried out improperly and by unqualified per-
sons may have serious consequences for the user!
We set traditionally high standards in the quality and
durability of our direct heaters. However, defects can
not always be completely ruled out. For problems with
devices please contact our service hotline.
11. Recycling
For electrical products sold within the Euro-
pean Community.
At the end of the electrical products useful life
it should not be disposed of with household
waste. Please recycle where facilities exist. Check with
your Local Authority or retailer for recycling advice in
your country.
www.dimplex.de
12. Spare parts
Ordering spare parts at Glen Dimplex Germany GmbH
on the Internet at:
www.dimplex.de/ersatzteile.html
13. Warranty
This product is supplied with a two-year warranty ac-
cording to our terms of guarantee.
This product corresponds to lot 20 of the Eco Design
Directive 2009/125/EC for individual room heating de-
vices (directive (EU) 2015/1188.
14. Technical Data
Model reference
Nominal voltage
Degree of protection
Dimensions (W x H x D)
Weight
Heat output
Nominal heat out-
put
Minimum heat
output (indicative)
Maximum contin-
uous heat output
Auxiliary electricity consumption
At nominal heat
output
At minimum heat
output
In standby mode
Type of control
Mechanical thermostat
Glen Dimplex Deutschland GmbH
Am Goldenen Feld 18
D - 95326 Kulmbach
RD9_EN.fm · 10/17/C
RD 907 RD 909
1/N/PE, 230 - 240 V~
IP20
370 x 620 515 x 620
x 285 mm x 285 mm
7.0 kg 8.7 kg
P 1.5 kW 2.0 kW
nom
P 1.0 kW 1.4 kW
min
P 1.5 kW 2.0 kW
max, C
el 0.0 W 0.0 W
max
el 0.0 W 0.0 W
min
el 0.0 W 0.0 W
SB
Tel.: +49 9221 709 545
Fax.: +49 9221 709 924 545
Email: service@gdts.one
English
RD 911
610 x 620
x 285 mm
10.6 kg
2.5 kW
1.7 kW
2.5 kW
0.0 W
0.0 W
0.0 W
EN-11
