5 – STARTUP GUIDE
Operating the equipment
Example :
The equipment is operated using the web browser.
!
Connect the "ETH" access of the equipment to the Ethernet board of the PC using the crossed Ethernet cable RJ45
"
The yellow led of the "ETH" connector on the equipment should come on.
!
Start the web browser
"
If the display is configured for 800x600, select the value "10" for the scalable font with NETSCAPE 4.x and "Smaller" with
INTERNET EXPLORER 5.x. ( See the web browser help menu to configure the font size ).
!
In the home screen, complete the "Address" field with the Equipment address (192.168.30.30)
!
The window Welcome on the ADR155C's site appears on the screen. By default, there is no Password. Click the "Apply" button.
!
The window ADR155C : Shelf view is displayed on the screen.
To operate the equipment, refer to the help menu by clicking the Help link on the main window.
Installation and User Guide - N56717020104
Page A5-8
Sub-network: 135.11.110.8
IP parameters
@IP
: 135.11.110.9
Mask
: 255.255.255.252
@Gateway
: 135.11.110.10
No reproduction or communication without the written consent of SAGEM SA
