1.3.6 - Connecting on ADR E3DS3 card
ADR E3DS3
STATUS
LED
Green
Red
ON
OFF
ON
ON
OFF
OFF
OFF
ON
Flashing
"TR" and "REC"ports :
Ports
Connector
No reproduction or communication without the written consent of SAGEM SA
STATUS
Card in service
Card in alarm
Hardware default (fuse)
Card out of service
Autotest default
Figure 1-7- Connecting on ADR E3DS3 card inputs
75 ohms 34/45 Mbit/s Interface compliant to ITU-T G.703
(§ 5 and 8) Recommendation and ETS 300 166 allowing 34 Mbit/s
or 45Mbit/s plesiochronous stream exclusive connection
BNC 75 ohms
1.6/5.6 75 ohms (with BNC - 1.6/5.6 adapter)
1 - INSTALLATION AND COMMISSIONING
34 or 45 Mbit/s transmission port
34 or 45 Mbit/s reception port
DS3
E3
TR
REC
45 34
LED
ON
34 Mbit/s Mode activated
OFF
45 Mbit/s Mode activated
Installation and User Guide - N56717020104
Page A1-19
