4. Technical data

Speed n .............................................8,500 min
0
Cutting circle .......................................... Ø 24 cm
Max. operating time ..................... approx. 40 min
Protection class ................................................III
L sound power level ............................... 94 dB
WA
L sound pressure level ............................ 78 dB
pA
Interchangeable battery ..... 18 V d. c. / 1500 mAh
Vibration ..................................................5,8 m/s
K uncertainty .......................................... 1.5 m/s²
Weight ....................................................... 2,2 kg
Charging unit
Mains voltage ............................... 230 V ~ 50 Hz
Output
Rated voltage ..................................... 21,3 V d. c.
Rated current ....................................... 1000 mA
The machine may exceed 85 dB (A). The operator
will require noise protection measures if this is
the case. The noise was measured in accordance
with prEN ISO 10518. The value of the vibrations
emitted by the handle was determined in ac-
cordance with prEN ISO 10518.
Important.
The vibration value changes according to the
area of application of the electric equipment and
may exceed the specifi ed value in exceptional
circumstances.
Reduce noise generation and vibration to a
minimum!
•
Use only equipment that is in perfect condi-
tion.
•
Maintain and clean the equipment regularly.
•
Adapt your way of working to the equipment.
•
Do not overload the equipment.
•
Have the equipment checked if necessary.
•
Switch off the equipment when not in use.
•
Wear gloves.
Anleitung_RG-CT_18_1_Li.indb 18 Anleitung_RG-CT_18_1_Li.indb 18
GB

5. Before putting into operation

5.1 Fitting the safety hood (Fig. 3-4)
-1
When fi tting the safety hood (Fig. 1/Item 8) make
sure that the edge guide (Fig. 1/Item 6) is in a po-
sition in which the blade head (Fig. 1/Item 7) does
not obstruct the fi tting. Push the guard hood (Fig.
1/Item 8) in the direction of the arrow onto the
motor housing as shown in Fig. 3. Make sure that
it latches in place correctly! Make sure that the
guard hood is fi tted as in Fig. 4.
2
5.2 Height adjustment (Fig. 5)
Undo the union nut (Fig. 5/Item 5) until the grass
trimmer handle can be moved in and out freely.
Now set the required working height (Fig. 6) and
secure the handle in this position by tightening
the union nut again.
5.3. Fitting the additional handle (Fig. 7)
Fit the additional handle to the mount provided,
paying attention to the teeth (Fig. 7/Item I & II).
Then secure the additional handle with the help
of the screw and the adjustment lock provided.
Make sure that the compartment for the spare
blades faces the top of the equipment.
5.4 Adjusting the additional handle (Fig. 8)
Undo the adjustment lock (Fig. 8/Item 3) for the
additional handle until it can be moved forwards
and backwards without any great resistance. Set
the required position and tighten the securing
screw again.
5.5 Adjusting the angle of tilt of the guide
handle (Fig. 9)
Press the button for the angle of tilt adjustment
(Fig. 9/Item K). Now you can set the long handle
to the required tilt. Release the button and allow
the handle to lock into position to fi x the angle of
tilt. Three diff erent locking angles are possible.
5.6. Installing the battery (Fig. 10/11)
Press the side pushlock buttons of the battery
pack as shown in Fig. 10 and push the battery
pack into the mount provided. When the battery
pack is positioned as in Fig. 11, make sure that
the pushlock buttons latch in place! To remove the
battery pack, proceed in reverse order.
5.7 Charging the battery (Fig. 12)
1. Take the battery pack out of the equipment.
Do this by pressing the side pushlock buttons.
2. Check that your mains voltage is the same as
- 18 -
