Assembly; Operation - Wolf Garten POWER WOLF 15/37 Mode D'emploi

Maintenance
1
Caution! Rotating cutters
Before all maintenance and cleaning tasks:
Pull the mains plug out.
Take care not to grab running cutters.
Check all the visible fixing bolts and nuts regularly for tight-
ness and retighten, particularly those of the cutter beam.
Do not store the mower in damp rooms.
For safety reasons, replace worn or damaged parts.

Assembly

Fasten handle bars
A
1
Caution!
The cable can be damaged while folding up or pulling out
the handle bar.
Inlay the cable in the bend protection
When adjusting the handle height take care that the ca-
ble is not crimped
1. Fold the bottom part of the handle up and screw it tight with
B
the two hand wheels
2. Set the handle to the desired height
3. Fold the upper part of the handle out and screw it tight with the
wing nuts D .

Operation

Operating times
Please check noise abatement regulations prevailing in your
country.
Feed cable through the strain relief
Please feed cable through the strain relief
Hang up collection bag
1
Attention! Rotary cutter blade
Undertake adjustments on the equipment only after the
motor is switched off and the cutting tool has come to a
standstill.
1. Lift the protective flap.
2. Hang the grass bag in the chassis with the hooks in the re-
cesses (see arrow).
3. Replace the protective flap.
Set cut height
K
1
Attention! Rotary cutter blade
Undertake work/adjustments on the equipment only after
the motor is switched off and the cutting tool has come to a
standstill.
1. Pull the lever out.
2. Set the desired cutting height.
3. Press the lever back in.
G
B C D
A .
C
.
C .
H
H .
J
Use only original WOLF spare parts, otherwise there is no gua-
rantee that your mower complies with the safety regulations.
Disposal
Electrical equipment must not be placed in the
household waste.The unit, accessories and pa-
cking material should be taken to an environment-
friendly recycling unit.
Mount the collecting bag
1. Place the chute (1) on the collecting bag flap (2)
2. Press the chute from behind onto the collecting bag flap. The
chute is ready for use as soon as it locks into place
Selection of Cutting height
If possible, mow when grass is dry in order to protect turf. Do
not se cutting position too low when mowing very hight or wet
grass.
We recommend an average cutting height of 40-50 mm.
Connecting to the mains (230 Volts, A.C., 50 Hz)
The mower operates from any normal household mains sup-
ply, provided with a 16 Amps. fuse.
3
Note: Residual current protection device
These protection devices safeguard while touching
damaged wires, from insulation flaws and in certain cases,
also while damaging live wires.
We recommend that the equipment only be plugged into
a power socket, which is protected by a residual current
protection device (RCD) with a residual current of not
more than 30 mA.
Retrofit kits are available for old installations. Consult an
electrician.
E F G
E F
G
.
.
