panel. The trigger range starts approx. 5-6 mm in front of the actuator plate. It is
possible, but not necessary, to touch the actuator plate to trigger the flush function.

6. Operation

You can make settings via the remote control (see 1.2 Remote control). The basic func-
tions - main flushing time, pre-flush, presence detection, reset - can also be set via
the membrane keypad

6.1 Settings via the membrane keypad

The membrane keypad is on the back of the actuator plate. You must remove the actu-
ator plate to make settings via the membrane keypad (see 6.1 Removing the actuator
plate).
(see 1.3 Membrane keypad)
2
1
on the back of the actuator plate.

Removing the actuator plate

> Press the actuator plate upwards.
> Release it from above.
39
