mulching plate.
SIDE DISCHARGE DOOR
Your mower is equipped with a door that covers the side
discharge opening, which allows the mower blade to cut
and recut the grass for fi ner clippings if the mulching plug
is engaged, or otherwise sends the grass clippings to the
collection bag.
ASSEMBLY
UNPACKING
This product requires assembly.
■ Carefully remove the product and any accessories
from the box. Make sure that all items listed in the
packing list are included.
Do not use this product if any parts on the packing list are
already assembled to your product when you unpack it.
Parts on this list are not assembled to the product by
the manufacturer and require customer installation. Use
of a product that may have been improperly assembled
could result in serious personal injury.
■ Inspect the product carefully to make sure no breakage
or damage occurred during shipping.
■ Do not discard the packing material until you have
carefully inspected and satisfactorily operated the
product.
■ If any parts are damaged or missing, please call your
Powerworks service centre for assistance.

PACKING LIST

■ Lawn mower
■ Battery key
■ Grassbox
■ Mulching plug
■ Side discharge deflector
■ Operator's manual
■ Knobs
■ Bolts
If any parts are damaged or missing do not operate this
product until the parts are replaced. Using a product
with damaged or missing parts could result in serious
personal injury.
English (Original Instructions)
WARNING
WARNING
Do not attempt to modify this product or create
accessories not recommended for use with this product.
Any such alteration or modification is misuse and could
result in a hazardous condition leading to possible
serious personal injury.
Do not insert battery key until assembly is complete and
you are ready to mow. Failure to comply could result in
accidental starting and possible serious personal injury.
To prevent accidental starting that could cause serious
personal injury, always remove the battery pack from
the product when assembling parts.
Never operate the mower without the proper safety
devices in place and working. Never operate the mower
with damaged safety devices. Operation of this product
with damaged or missing parts could result in serious
personal injury.
UNFOLDING AND ADJUSTING LOWER HANDLE
See figure 2.
■ Pull and rotate the handle knobs 90° on both sides to
loosen the lower handles on both sides.
■ Move the lower handles to the operating position. You
may raise or lower the handle to a position comfortable
for you. There are 3 positions for you to choose.
Release the handle knobs to lock the lower handle
into position.
NOTE: Ensure both sides are set at the same position for
proper assembly.
INSTALLING THE UPPER HANDLE
See figure 3.
■ Align the mounting holes on the upper handle and the
lower handle. Insert the carriage bolts and use the
knobs to tighten them. Repeat the operation on the
other side.

INSTALLING THE GRASSBOX

See figure 4.
■ Lift the rear discharge door.
■ Lift the grass catcher by its handle and place under
the rear discharge door so that the hooks on the grass
2
