COMPACT 3.0
INSIDE CABIN:
6
Screw about 5 mm (4) 8/125x70,100 or 120
mm studs, the exact measure is chosen after
the fastening supports have been presented
and taking into account that studs must stick
out of lower part about 20 mm.
6
Colocar (1) arandela Ø 7 de goma, (1) arandela
7
plana Ø 8 ala ancha, (2) tuerca M8 y (1) arandela
plana Ø 8 ala ancha , en cada uno de los
espárragos anteriores; siguiendo dicho orden.
7
Unit base
6
7
17
®
5 mm
Stud
Bracket
20 mm
6
6
EN
