General description

The room climate station is required for detecting the room tem-
perature and humidity with silent cooling. It is connected to a re-
versible heat pump manager and uses the measured reference
room temperature and humidity for controlling.
2 Mounting
The casing of the room climate station must be opened as shown
in the following figures and mounted using the supplied mounting
material.
You can use the drill template in the packaging cover or the di-
mension drawing below for drilling the holes.
Measuring ranges:
Room temperature:-10 °C - +60 °C
Room humidity:10% rH - 90% rH
