Evolution R185CCS Notice Originale page 13

www.evolutionpowertools.com
1
2
3
4
5
6
7
23 24
1. CUT MATERIAL EJECTION PORT
2. THUMB LEVER
3. MULTI-MATERIAL TCT BLADE
4. LOWER BLADE GUARD
5. PARALLEL EDGE GUIDE
6. ERGONOMIC FRONT HANDLE
7. CARBON BRUSHES
8. 5/16" HEX KEY (BLADE CHANGE)
9. DEPTH ADJUSTMENT LEVER
USA
16
17
12
8
25
10. DEPTH SCALE
11. REAR HANDLE ON/OFF SWITCH
12. UPPER BLADE GUARD
13. PRECISION ENGINEERED TRACK
COMPATIBLE SOLE PLATE
14. THUMB LEVER
15. REAR PROTRACTOR SCALE
16. ARBOR LOCK BUTTON
17. LED LIGHT
13
18
21
19
14
13
20
11
10
15
22
9
18. DUST PORT CONNECTOR
19. 25/32" INNER BLADE FLANGE
20. 5/8" INNER BLADE FLANGE
21. TRACK ADJUST TURN BUTTONS
22. REAR BEVEL THUMB SCREW
23. 3x 13-3/8" TRACK
24. 4x TRACK CONNECTOR BARS
25. 1/8" HEX KEY (TRACK)
EN
ES
DE
FR
IT
PL
PT
RO
