External error messages on display of the SPC terminal; accurate, automatic error messages:
Error Display Legend
No.
1
2 Back-up failed.
3 Back-up failed.
5 Back-up failed.
6 Back-up failed.
7 Back-up failed.
20 Back-up failed.

4. Recommendations

Configuration files relate to both equipment and use and as such are not transferable. Do not misuse, transfer to third parties or handle carelessly.
Stored files or other storage media must be archived properly so that they can be easily traced without leaving them open to misuse. If there are any
requirements relating to analysis, correction, compensation etc., files containing the updated data in question must be transferred to Flamco Support
or Service as an attachment to an e-mail message. Flamco Service or the qualified representative will make any changes on-site only. If a more
recent version of the software is available, this change may also cover a software update (as part of a general update). Any data written on the card
is permanent, i.e. it remains if the control unit is switched off or the power supply is interrupted in any way.

5. Configuration file, examples.

6
Description
The expansion module is not
available or not completely
inserted (version number not
shown).
The write-protect is activated
(lock on).
The card has not been formatted. Use a formatted card. Repeat process under initial
Card does not have enough
space to write data.
Error while reading one of the
files.
Error when closing one of the
files.
General error, e.g.: Time out as a
result of lack of card or card not
in lock-in position.
Readout 1
Open folder on a removable drive.
Software version up to 1.1.5 (Menu [11-3-1]*):
Saving will overwrite an open file.
This means that there will only be a storage record of the last
saving.
Readout 2
Open folder on a removable drive.
Software version from 1.1.6 (Menu [11-3-1]*):
File will be saved in a subdirectory. The folder will be named with
the serial number of the control unit.
Readout 2.1
The highlighted file contains the data record of the last time the
configuration file was saved (updated).
Readout 2.2
It is possible to open a file with a suitable editor (XML Notepad). If
data in this file is changed it will become invalid and not suitable
for re-use. The data record shown is that of the file highlighted in
readout 2.1.
Aggregate ID:
Order no.:
Version:
Date and time of saving:
Actual value of entry under:
Serial no.:
Error history:
Top-up list (topping-up/draining):
Action
Insert expansion module correctly, push card to
lock-in position.
Remove card, deactivate write protect (lock off)
and insert card to the lock-in position. Repeat
process under initial conditions.
conditions.
Use a card with at least 200 Kb of available
memory (storage record). Repeat process under
initial conditions.
Repeat process under initial conditions.
Repeat process under initial conditions.
Repeat process under initial conditions.
Menu [11-2-1]*
Menu [11-1-1]*
Menu [11-3-3]*
Menu [3]*
Menu [11-3-1]*
Menu [11-6-1]*
Menu [11-8-3]*
