USB Specification:
Interface
- USB 2.0 Full speed, HOST (USB HUB is not supported) Corresponding Flash memory
- Compatible with MPEG Audio 1, 2, 2.5
- Compatible with Layer 1, 2, 3
- Compatible with Bit rate: 128 – 320 Kbps
- Subfolder nest : 8 levels
- Number of track / titles max 999
- Support ID3 tag V2.0
TURNTABLE
PREPARING TO USE THE TURNTABLE
1. Lift up lid and remove black tie-wrap by untwisting and gently sliding out from TONE ARM
2. Remove cardboard shipper.
3. Remove white protective needle cover by gently pulling towards front of unit.
4. Release TONE ARM and hold-down clip by gently pushing to the right.
This will unlock tone arm from its ARM REST. Re-lock the hold-down clip when moving the unit
to another location.

TURNTABLE OPERATION

1. Slide the FUNCTION Switch to PHONO mode.
2. Switch the unit ON by turning the POWER switch to the on Position.
3. Turn the VOLUME control in mid-range position.
4. Set the SPEED CONTROL SWITCH to the correct speed (33 1/3, 45 or 78 rpm) for the selected
record.
5. Move the tone arm over the record and lower it to the point you want the record to start.
6. At the end of the record, the TONE ARM will stop automatically. You must return it to the TONE
ARM REST by hand.
ACCESSORY SUPPLIED :
Adaptor for 45 rpm records
To play a 45 rpm record, remove the adaptor by placing thumb &
forefinger in recesses and pulling it upwards.
Then placing it on the SPINDLE. The record can then be placed on the turntable.

PROGRAMMING TRACKS

You may store up to 20 tracks in the desired sequence.
1. In the stop position, press PROGRAM /
P CD
2. Press the FORWARD SKIP/
number appears in the display.
3. Press PROGRAM /
P
CD
/ BACKWARD SKIP/
to confirm, display shown stored track no. and next store position.
to start programming. Icon "P" and P0-01 start flashing.
once or repeatedly until the desired track
