HSI150 DFK
Contents
1

Publishing notes ...............................................10

2

Explanation of symbols ....................................10

3 Required tool and auxiliaries ...........................10
4 Description ........................................................10
5

Preparing for assembly ....................................10

6 Mount the HSI150 DFK .....................................10
1 Publishing notes
Copyright © 2020 by
Hauff-Technik GmbH & Co. KG
Dept.: Technical Editing
Robert-Bosch-Straße 9
89568 Hermaringen, GERMANY
Tel. +49 7322 1333-0
Fax +49 7322 1333-999
E-mail offi ce@hauff-technik.de
Internet www.hauff-technik.de
Reproduction of these assembly instruction – even in
extracts – in the form of reprint, photocopy, on electro-
nic data media or using any other method requires our
written consent.
All rights reserved.
Subject to technical alterations at any time and without
prior announcement.
These assembly instruction is component of the product.
Printed in the Federal Republic of Germany.
2 Explanation of symbols
1
Work stages
►
Effect/result of a work step
1
Reference numerals in drawings
3 Required tool and auxiliaries
To install the HSI150 DFK correctly, you will need the
following tools and auxiliaries:
1 Torque spanner
1 Wrench insert, SW13/T40
1 Adhesive and sealant EGO MS 805
(Article no.: 3030300027)
4 Description
Description: HSI150 DFK (see fi g.: 1).
Legend for fi g.: 1
1 Core drill max. Ø 150 mm
2 Surface seal
3 HSI150 DFK
4 Dowel
5 Screws with sealing ring
10
5
1
6
1
2
Legend for fi g.: 3
1
3
4
Art. Nr.: 5090020159 Rev.: 00/2020-01-14
Preparing for assembly
The outside of the building must be level, dry
and clean prior to installation! Thoroughly
remove, smooth and level out any unevenness
on the wall surface in the fl ange area.
Mount the HSI150 DFK
Centre the fl ange over the existing opening.
Align horizontally using the integrated level and
mark the dowel holes (see fi g.: 2).
Mounting distances:
• According to DIN 18533 with PMBC (W1-E
to W2.1 E): min. fl ange outer edge to fl ange
outer edge, to other components, to building
edges.
Distance: min. 150 mm.
Distance to building joints: min. 300 mm.
• Waterproof concrete: Center distance min.
250 mm with multiple arrangement.
Then drill the dowel holes (Ø 10 mm, 80 mm deep)
and clean see fi g.: 3).
Core drill max. Ø 150 mm
For assembly, the adhesive and sealant EGO
MS 805 (not included in the scope of delivery,
accessories) is to be used, which achieves a
complete adhesion to the substrate. Use with
PMBC thick coating (KMB) according to DIN EN
15814:
The basis for mounting on wall surfaces with
PMBC thick coatings is a professionally executed
building sealing according to DIN 18533-3 and
a fully cured thick coating.
If the surface is uneven, a coating of adhesive and
sealant (not included in scope of delivery) must also
be applied in the preformed seal recesses at the rear
of the fl ange (see fi g.: 4).
Fastening elements for installation on metal
housings are not included in the scope of
delivery! With all other wall elements except
for concrete or masonry, suitable pressure-tight
fi xing elements must be selected and tested
independently. When making a selection, it is
important to ensure that no infi ltration occurs
on the system as a result of the fi xing elements
used on-site.
Following this, press the fl ange onto the wall and
use the pre-installed screws to insert the fastening
dowels and sealing rings until the dowel shaft is
inside the fl ange base and is fl ush with the surface
of the wall (see fi g.: 5).
EN
