Accessories and tools
Required accessories
• 1 x Zacki2 Elapor
®
20g
• 2 x HS-65HBM
• 1x receiver RX-5 light M-LINK 2.4 GHz
• Glider needed
• 1 x Roxxy 3A UBEC
• battery Roxxy 2/450
EN
• Electro needed
• 1x power kit FunWing (for version with motor)
with motor ROXXY BL Outrunner C27-13-1800kV,
ROXXY BL-Control 715 S-BEC,
propeller set 5.5" x 4"
• 1x battery ROXXY EVO LiPo 3/1000 30C
Optional accessories
• Receiver RX-5 M-LINK telemetry-capable
• Transmitter COCKPIT SX 9
• Zackivator
®
List of parts
Serial no. Qty.
Name
1
1
Complaints form for models
2
1
Decal sheet
3
1
Wing with glued EPP leading edges
4
1
Winglet, right
5
1
Winglet, left
6
1
Canopy
7
1
Motor pod, upper part
8
1
Motor pod, lower part
9
1
Spar
10
1
Spar
11
1
Bulkhead
12
1
Right servo hood
13
1
Left servo hood
14
2
Glue-in rudder horn
15
6
Magnet holder, small
16
2
Magnet holder, large
17
1
Battery plate
18
1
Hook and loop strap
19
2
Mushroom head hook and loop tape
20
2
Velour hook and loop tape
21
2
Pushrod connector
22
2
Washer
23
2
Nut
24
2
Hexagon socket set screw
25
1
Hex key
26
2
Steel wire Ø1.3 mm x 140 mm for aileron
27
6
Magnet, small
28
2
Magnet, large
10
Bedienungsanleitung-FUNWING-04.indd 10
Bedienungsanleitung-FUNWING-04.indd 10
Required tool
# 1-01291
• Scissors
# 1-02232
• Cutter
# 55808
• Universal pliers
• Punch Ø 4-5 mm or small round file
# 1-02227
• Hot glue
# 1-00016
Specifications
# 1-01857
Wingspan
Overall length
Flight weight above
# 1-01957
RC functions
# 55817
# 45161
# 1-01032
Material
Printed adhesive film
Foamed Elapor, white
Foamed EPP, orange
Foamed EPP, orange
Foamed Elapor, white
Foamed Elapor, white
Foamed Elapor, white
CFRP
CFRP
Injected plastic
Injected plastic
Injected plastic
Injected plastic
Injected plastic
Injected plastic
Injected plastic
Plastic
Plastic
Plastic
Metal
Metal
Metal
Metal
Metal
Metal
Magnet
Magnet
1160 mm
620 mm
390 g Glider
485 g Electro
Ailerons, motor control
Dimensions
Finished component
Finished component
Finished component
Finished component
Finished component
Finished component
6 x 1.5 x 300 mm
5.5 x 3 x 5 x 400 mm
Finished component
Finished component
Finished component
Finished component
Finished component
Finished component
Finished component
188 x 13 mm
25 x 60 mm
25 x 60 mm
Finished component
M2
M2
M3 x 3 mm
WAF 1.5
Ø1.2 mm x 140 mm
6 x 5 x 1.8 mm
10 x 4 x 2 mm
31.03.2021 09:39:52
31.03.2021 09:39:52
