System requirements

Before installing the Active Panel pen display, make sure your computer meets the following
system requirements:
• PC. Windows XP, XP x64, 2000, Me, or 98SE. VGA video connector, available USB port, and
CD-ROM drive.
• Macintosh. OS X, v10.2.8 or greater. VGA video connector, available USB port, and
CD-ROM drive.
Note: The Active Panel can be used alone or with another display. You may connect a second
VGA device such as a monitor or LCD projector to the Active Panel
When using this port, the second device will mirror the image on the pen display. Complete the pen
display installation before connecting a projection device to the unit.
Depending on the capabilities of your video card and operating system, you may be able to set up
the Active Panel as a mirrored, extended, or independent display. Refer to your video card
documentation for more information on its capabilities.
When you are working with more than one monitor, the Active Panel will map to the monitors
based upon how your system is configured. By default, if you are in mirror mode, the pen tablet will
map to the entire space on each display or monitor. Please refer to your hardware and operating
system documentation for details on configuring your computer and operating system for use with
multiple monitors.
There are two primary steps to the installation process:
• Step 1: LCD monitor installation
• Step 2: Pen tablet installation
Be sure to follow ALL instructions carefully.

INSTALLATION

OUT port.
ANALOG RGB
Installation
page 9
