ENGLISH
MATCH COUNT key. It increases the number of matches. Since there is a 3-match limit, 1, 2 or 3 lights are
displayed.
CART. JAUNE keys (right and left). They assign and remove the "yellow card" penalty.
CART. ROUGE keys (right and left). They assign the "red card" penalty, which causes a point to be assigned to
the adversary.
P. MAN. key (Manual priority). It assigns and removes the priority.
P. CAS. key (Random priority). It randomly assigns priority. Pressing the key again removes the priority.
BLOCK key. It is not utilized at the moment.
5. R C
EMOTE ONTROL
The remote control runs on a 9V alkaline battery.
It transmits approximately 150˙000 commands.
To replace the battery, the two screws on the rear side must be removed. Alkaline batteries are recommended
because their life is about 4 times longer than the carbon-zinc cell. Correct functioning of the remote control is
shown by a red light on it, while correct reception is indicated by an illuminated yellow light (TÉLÉCOM.RÉCEPT.)
on the FA05. Note that if the signal received comes from another remote control, the yellow light will be weaker.
The remote control operates by using infrared rays, so it is important to point it directly at the FA05 (similar to a
television remote control). Every remote control has a unique, unalterable and inaccessible transmission code and
every FA05 can be programmed to recognize any remote control, but only one at a time. Thanks to these
features, two remote controls can never control the same apparatus. Furthermore, there is no limit to the number
of apparatus that can be connected in the same fencing arena. The remote control supplied with the FA05 is
already prepared, so acquisition is necessary only when the remote control is changed.
For the aforementioned acquisition procedure, see the two preceding chapters.
6. F -A -05 O
ULL RM
Please read Chapter "3. Full-Arm-05 Keyboard" and Chapter "4. Remote Control keyboard", where all the
functions of the keys are described.
Two LIGHTS-REPEATERS (Art.894) can be connected to the 2 DATA-LINE sockets, located on the back of the
FA05.
An inexpensive connector doubler (Art.880), useful for doubling a DATA-LINE output, is also available.
To prevent the annoying continuous noise that occurs in the sabre and the foil when the fencers are not
connected, the programme inhibits the sound after a set period of time from when both weapons have been
disconnected. Also the white lights are switched off to limit consumption. As soon as a weapon is connected, the
signals appear again.
7. F -A -05 A
ULL RM
For the various accessory articles available for running the FA05, such as transformers, batteries and battery
chargers, see Chapter "2. Battery-Run Operation".
Art.852 - BOX-04 Carrying case
In addition to the FA05, this case can also house other accessories, such as the battery (Art.828), the battery
charger (Art.169) and the 1m high table-top stand (Art.873).
Art.873 - 1m high table-top stand
Useful for positioning the FA05 above the level of the fencers. When disassembled into two pieces, this stand can
be inserted into the carrying case Art.852 BOX-04. A clamp is provided for anchoring the stand to the table as well
as 1.2m extension cord, if the power cord must be lengthened.
Art.880 - DATA-LINE Doubler
If it is necessary to connect more than 2 repeaters, this inexpensive accessory connector can double a single
DATA-LINE output.
Art.894 - LIGHTS REPEATER
Power supply: there are 3 versions.
• Art. 894-A: for 230V power supply, 6VA max.
• Art. 894-B: for 115V power supply, 6VA max.
• Art. 894-C: for 12V power supply, 400mA max.
00831-M01-01 - Full-Arm-05 User Manual
O
PERATIONS
PERATIONS
CCESSORIES
6 / 28 F E S
AVERO LECTRONICS RL
