BACKLIGHT

The backlight of Teambox can be adjusted the brightness level of both radio on mode
and radio standby mode.
Radio on
You can set the brightness level of radio on mode.
Press the Power button to switch on the radio.
1.
2. Press the Tuning << or Tuning >> button to select "System settings" and press
the Select / Info button to enter system menu.
3. Then press the Tuning << or Tuning >> button to select "Backlight" and press the
Select / Info button to confirm.
4. Press the Tuning << or Tuning >> button to select "Radio on" and press the
Select / Info button.
5. Press the Tuning << or Tuning >> button to select from High / Medium / Low / Off,
then press the Select / Info button to confirm.
Standby
You can set the brightness level of radio on mode.
1. Press the Power button to switch on the radio.
2. Press the Tuning << or Tuning >> button to select "System settings" and press
the Select / Info button.
3. Then press the Tuning << or Tuning >> button to select "Backlight" and press the
Select / Info button to confirm.
4. Press the Tuning << or Tuning >> button to select "Radio standby" and press the
Select / Info button to confirm.
5. Press the Tuning << or Tuning >> button to select from High / Medium / Low / Off,
then press the Select / Info button to confirm.
23

ADDITIONAL METAL TELESCOPIC ANTENNA

You can use this as an alternative antenna for your radio in areas or locations where the
radio-signal (FM/DAB/DAB+) is weak to very weak.
ATTENTION: the standard antenna on the radio is flexible, this antenna is not
flexible.
Installing: Carefully screw off the standard flexible antenna. First carefully loosen the
antenna screw by a screwdriver – turn counter clockwise.
Carefully screw on the metal telescopic antenna and tighten it by a screwdriver – turn
clockwise.
ATTENTION: do not use too much force when fixing the antennas as this can
damage the screw threat of the antennas or make it break off.

WARRANTY

This radio has a 2 year limited warranty.
WARNING ! Warranty becomes void once the radio cabinet has been opened or
any modifications or alterations to the radio have been made !
The terms of the warranty of this radio do not cover the following:
• Damage caused by misuse, abuse, neglect, alterations, accidents or unauthorized
repair.
• Normal wear and tear.
Breaking or bending of the metal telescopic antenna
•
Never open the device casing. The manufacturer will not accept any liability for damage
resulting from improper handling. The type plate is located on the bottom of the device.
