TECHNICAL DATA RADIO CHARGER
AC/DC Adaptor input ........................................................................
AC/DC Adaptor output ......................................................................
Rated input .......................................................................................
Battery Voltage .................................................................................
Weight without packing and battery ..................................................
Tuning range AM ..............................................................................
Tuning range FM ..............................................................................
Tuning range DAB+ ..........................................................................
Charger output..................................................................................
Quick charge current ........................................................................
USB output .......................................................................................
Bluetooth Version .............................................................................
Frequency band(s) of Bluetooth .......................................................
Maximum radio-frequency power transmitted
in the frequency band(s) ...................................................................
Charge Time
Li-Ion 12 V / 1.5 Ah ............................................................... about
Li-Ion 12 V / 2.0 Ah ............................................................... about
Li-Ion 12 V / 3.0 Ah ............................................................... about
Li-Ion 12 V / 4.0 Ah ............................................................... about
Li-Ion 12 V / 6.0 Ah ............................................................... about
Recommended ambient operating temperature ...............................
Recommended battery Type ............................................................
WARNING! Read all safety warnings and all
instructions. Failure to follow the warnings and instructions
may result in electric shock, fi re and/or serious injury.
Save all warnings and instructions for future reference.
RADIO SAFETY WARNINGS
Never disassemble or modify this apparatus in any way.
Do not use this apparatus near water.
Clean only with dry cloth. Certain cleaning agents and
solvents are harmful to plastics and other insulated parts.
Keep the apparatus handle clean, dry and free of oil or
grease.
Refer all servicing to qualifi ed service personnel.
Do not install near any heat sources.
The ventilation should not be impeded by covering the
ventilation openings with items, such as newspapers,
table-cloths, curtains, etc.
No fl ame sources, such as lighted candles, should be
placed on the apparatus.
It shall not be exposed to dripping or splashing and that no
objects fi lled with liquids, such as vases, shall be placed on
the apparatus.
Do not place the product in closed bookcases or racks
without proper ventilation.
Where the mains plug is used as the disconnect device, the
disconnect device shall remain readily operable.
Do not stand on unit.
Warning! To reduce the risk of fi re, personal injury, and
product damage due to a short circuit, never immerse your
tool, battery pack or charger in fl uid or allow a fl uid to fl ow
inside them. Corrosive or conductive fl uids, such as
seawater, certain industrial chemicals, and bleach or bleach
containing products, etc., can cause a short circuit.
CHARGER SAFETY WARNINGS
Do not dispose of used battery packs in the household
refuse or by burning them. Milwaukee Distributors off er to
retrieve old batteries to protect our environment.
Do not store the battery pack together with metal objects
(short circuit risk).
Use only Milwaukee M12 System chargers for charging
Milwaukee M12 System battery packs. Do not use battery
packs from other systems.
Caution! Danger of explosion if battery is incorrectly
replaced. Replace only with the same or equivalent type.
30 ENGLISH
M12 RCDAB+
..................... 100-240 V
.............................. 14 V
.............................. 42 W
.............................. 12 V
........................... 1,75 kg
................. 522 - 1620 kHz
.................. 87,5 - 108 MHz
................... 174 - 240 MHz
.............................. 12 V
................................ 1 A
.................. 5,0 V / 2,1 A
............................. 4.2
................. 2402-2480 MHz
........................... 5,81 dBm
............................. 1,5 h
................................ 2 h
................................ 3 h
................................ 4 h
................................ 6 h
.........................-18 .... +40 °C
..............................M12B...
The following battery packs can be charged with this
charger:
Battery Cat. Cell Type DC Volts Capacity
No.
M12B Li-Ion 12 V ≤ 1.5 Ah
M12BX Li-Ion 12 V ≤ 3.0 Ah
M12B2 Li-Ion 12 V ≤ 2.0 Ah
M12B3 Li-Ion 12 V ≤ 3.0 Ah
M12B4 Li-Ion 12 V ≤ 4.0 Ah
M12B6 Li-Ion 12 V ≤ 6.0 Ah
Do not try to charge non-rechargeable batteries with this charger.
No metal parts must be allowed to enter the battery section
of the charger (short circuit risk).
Caution!
Risk of explosion if the battery is replaced by an incorrect
type;
- high or low extreme temperatures that a battery can be
subjected to during use, storage or transportation,
- low air pressure at high altitude,
- replacement of a battery with an incorrect type that can
defeat a safeguard (for example in the case of some
lithium battery types),
- disposal of a battery into fi re or a hot oven, or
mechanically crushing or cutting of a battery,
- or leaving a battery in an extremely high temperature
surrounding environment that can result in an explosion or
the leakage of fl ammable liquid or gas,
- or a battery subjected to extremely low air pressure that
may result in an explosion or the leakage of fl ammable
liquid or gas.
Never break open battery packs and chargers and store
only in dry rooms. Keep dry at all times.
Do not touch the tool with conducting objects.
Never charge a damaged battery pack. Replace by a new
one.
Before use check machine, cable, and plug for any
damages or material fatigue. Repairs should only be carried
out by authorised Service Agents.
This appliance is not intended to be used or cleaned by
persons with reduced physical, sensory or mental
capabilities, or lack of experience or knowledge, unless they
have been given instructions concerning the safe use of the
appliance by a person legally responsible for their safety.
They should be supervised whilst using the appliance.
Children shall not use, clean or play with this appliance,
which when not in use should be secured out of their reach.
SPECIFIED CONDITIONS OF USE
The radio charger can charge Milwaukee System 12 V
batteries.
The radio is suitable for reception of broadcasting and to
import audio sound of diff erent devices via Bluetooth and
analog audio connection.
Via USB connection the radio can charge USB devices.
This radio is designed to withstand harsh operating
environments as well as unintentional drops.
Do not use this product in any other way as stated for
normal use.
EC-DECLARATION OF CONFORMITY
Hereby, Techtronic Industries GmbH declares that the radio
equipment type M12 RC is in compliance with Directive
2014/53/EU. The full text of the EU declaration of conformity
is available at the following internet address: http://services.
milwaukeetool.eu.
MAINS CONNECTION
Connect only to single-phase a.c. current and only to the
system voltage indicated on the rating plate. It is also
possible to connect to sockets without an earthing contact
as the design conforms to safety class II.
Cell No.
BATTERIES
3
2 x 3
Low Battery Indicator:
When the radio is powered by a battery pack and its charge
3
falls below 10%, the low battery indicator
3
2 x 3 Battery Pack Protection:
To protect the life of the battery pack, the radio will shut off
2 x 3
when the battery's charge becomes too low. If this happens,
plug radio charger to a mains connection and charge the
battery pack.
Battery packs which have not been used for some time
should be recharged before use.
Temperatures in excess of 50°C (122°F) reduce the
performance of the battery pack. Avoid extended exposure
to heat or sunshine (risk of overheating).
The contacts of chargers and battery packs must be kept
clean.
For an optimum life-time, after use, the battery packs have
to be fully charged.
CHARGER CHARACTERISTICS
After inserting the battery into the reception of the charger
the battery will automatically be charged (red lamp is
illuminated continuously)
When a hot or cold battery pack is inserted into the charger
(fl ashing red lamp), charging will begin automatically once
the battery reaches the correct charging temperature
(0°C...60°C).
Charging time varies depending on the battery temperature,
charge needed and the type of battery pack being charged.
If both LEDs fl ash at the same time, either the battery has
not been completely mounted or there is a fault in the
battery or the charger. For safety reasons you must stop
using the charger and battery immediately and have them
inspected by an Milwaukee Customer Service Centre.
BUTTONS
• Power on
• Power off
• cycle between DAB, FM, AM
• Bass and treble - press and hold
• enter menu - press and hold
• select menus
• cycle trough presets in AM or FM mode
• display time
• setting time - press and hold
• entering Bluetooth mode directly
• Volume
• tuning in AM or FM mode
• seeking in AM or FM mode - press and hold
• selecting in DAB mode next station
• skipping in Bluetooth mode
• cycle between menu items
is displayed.
BLUETOOTH
Pairing (Koppelung)
Für die erste Verbindung zu einem Bluetooth-Gerät, muss das
Pairing durchgeführt werden.
Bluetooth-Taste drücken (2 Sek. drücken).
Wenn kein Bluetooth-Gerät verbunden ist, startet das
Bluetooth-pairing automatisch und das Symbol
blinkt.
Das Radio sucht 3 Minuten nach einem Signal von einem
Bluetooth Gerät.
Für manuelles pairing die Bluetooth Taste
halten bis das Symbol blinkt.
Während das Symbol blinkt am Bluetooth Gerät "M12
Radio Charger" auswählen.
Bei manchen Geräten ist es notwendig die Pin "0000"
einzugeben.
Nachdem das Bluetooth Gerät mit dem Radio verbunden ist,
wird die das Symbol im Display angezeigt.
Verbinden
Blutetooth-Taste drücken.
Wenn das Radio ein bereits gekoppeltes Bluetooth Gerät
erkennt, wird der Name des Bluetooth Gerätes im Display
angezeigt.
Wenn die Verbindung zwischen Radio und dem Bluetooth-
Gerät verloren geht, wird das Radio 3 Minuten lang versuchen
die Verbindung wieder herzustellen.
Fernsteuerung
Verbundene Bluetooth Geräte können über die Start- und
Pause-Taste ferngesteuert werden. Um zwischen den Liedern
hin- und herzuspringen die ◄ und ► Tasten benutzen.
ENGLISH
im Display
drücken und
