System Map: Front View With Lcd Panel Open - Models A & C - Clevo M7X0TU Guide Utilisateur Concis

System Map: Front View with LCD Panel
Open - Models A & C
3
5
8
10
9
1
2
3
4
6
7
System Map: Front View with LCD Panel Open - Models A & C - 9
Wireless Device
Operation Aboard Aircraft
The use of any portable electronic
transmission devices aboard air-
craft is usually prohibited. Make
sure the wireless modules are
OFF if you are using the com-
puter aboard aircraft.
Use the key combinations to tog-
gle power to the 3.5G/WLAN/
Bluetooth modules, and check
the LED indicator icon to see if the
modules are powered on or not
(see Table 2 on page
Table 4 on page 13).
10
Concise User's Guide
Figure 2
Front View with LCD
Panel Open
(Models A & C)
1. Built-In PC Camera
(Optional)
2. LCD
3. Speakers
4. Power Button
5. Hot-Key Buttons
6. Keyboard
7. Built-In Microphone
8. Touchpad & Buttons
9. Fingerprint Module
(Optional)
10. LED Indicators
11/
8
TouchPad button
(valid operation area)
