System Map: Front View with LCD Panel Open (Models A & B)
3
Model A
15.6" (39.62cm)
6
1. PC Camera
2. *PC Camera LED
*When the PC camera is in use, the
LED will be illuminated.
8
2 1 3
4
6
5
7
8
9
Figure 4 - Front View with LCD Panel Open (Models A & B)
3. Built-In Array Microphone
4. LCD
5. Power Button
6. Speakers
3 2 1 3
4
Model B
17.3" (43.94cm)
6
7
8
9
7. Keyboard
8. Touchpad & Buttons
9. Fingerprint Reader
(Optional)
6
5
