Intimidator™ Wave 360 IRC QRG
Control Panel
Description
Menu Map
Main Level
Address
Run Mode
Setup
Screen Reverse
Dimmer Curve
Dimmer Speed
All manuals and user guides at all-guides.com
Button
<MENU> Exits from the current menu or function
Navigates upwards through the menu list or increases the
<UP>
numeric value when in a function
Navigates downwards through the menu list or decreases the
<DOWN>
numeric value when in a function
Enables the currently displayed menu or sets the currently
<ENTER>
selected value into the selected function
Programming Levels
001–512
DMX
Auto Auto01–Auto16
Sound
Slave S-1–S-4
IR
Mast Set M-1–M-4
Pan Revers
Tilt Reverse
Pan Angle
Tilt Angle
Display
Linear
SCurve
I Square
Square
Smooth
Sensitivity 1–100
Reset
Factory Reset
Function
Sets DMX starting address
17CH
Sets DMX personality
33CH
Sets an auto program
Sets a Slave mode
Sets Infrared mode
Sets a Master mode of M-1, M-2 or M-4
ON
Sets reverse pan operation
OFF
ON
Sets reverse tilt operation
OFF
540
360 Sets pan angle range
180
90
180 Sets tilt angle range
270
ON
Sets display blackout
OFF
ON
Sets screen orientation
OFF
Sets the dimmer curve mode
Sets the dimmer speed
Fast
Sets sound sensitivity
Resets all motor defaults
Resets to factory defaults
5
EN
Description
