DESCRIPTION OF THE DEVICE
GB
1� Light
2� Balcony (Fridge)
3� Water tank
4� Glass shelf (Fridge)
NOTE: The appliance design is subject to change without prior
notice�
46
5� Balcony (Freezer)
6� Glass rack (Freezer)
7� Freezer drawer
8� Fridge crisper
INSTALLATION
Ventilation condition
The position you select for the refrigerator installation should be
well-ventilated and has less hot air. Do not locate the refrigerator
near a heat source such as cooker, and avoid it from direct
sunlight, thus guaranteeing the refrigeration effect while saving
energy consumption. Do not locate the refrigerator in the damp
place, so as to prevent the refrigerator from rusting and leaking
electricity. The result of the total space of the room in which the
refrigerator is installed being divided by the refrigerant charge
amount of the refrigerator shall not be less than
1m³(space)/8g(refrigerant).
NOTE: The amount of refrigerant charged for the refrigerator can
be found on the nameplate.
Heat dissipation space
When working, the refrigerator gives off heat to surroundings.
Therefore, at least 30mm of free space should be spared at the
top side, more than 100mm on both sides, and above 50mm at
the back side of the refrigerator.
Dimensions in mm:
W
D
H
A
912
704
1770
1524
Note: Figure 1, Figure 2 only illustrate the space demand of the
product.
Level ground
Place the refrigerator on the solid and flat ground (floor) to keep
it stable, or else, it will give rise to vibration and noise.
B
C(°)
E
F
1062
160
50
100
GB
47
