PRODUCT DIMENSIONS - MRFF4136RZ and MRFF4236RZ
WARNING
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
Type
Standard
Electrical: A 115 V, 60 Hz AC only, 15 A or 20 A fused, grounded
electrical supply is required. It is recommended that a separate
circuit serving only your refrigerator be provided. Use an outlet that
cannot be turned off by a switch. Do not use an extension cord.
Water: A cold water supply with water pressure of between 35 psi
and 120 psi (241 kPa and 827 kPa) is required to operate the water
dispenser and ice maker. If you have questions about your water
pressure, call a licensed, qualified plumber.
WARNING
Explosion Hazard
Keep flammable materials and vapors, such as
gasoline, away from refrigerator.
Failure to do so can result in death, explosion, or fire.
To ensure proper ventilation for your refrigerator, allow for a 1/2" (12.7 mm) space on each side and at the top. Allow for a 1.97" (50 mm)
space behind the refrigerator. If your refrigerator has an ice maker, allow extra space at the back for the water line connections. When
installing your refrigerator next to a fixed wall, leave a 3
to swing open.
NOTE: This refrigerator is intended for use in a location where the temperature ranges from a minimum of 55°F (13°C) to a maximum of
110°F (43°C). The preferred room temperature range for optimum performance, which reduces electricity usage and provides
superior cooling, is between 60°F (15°C) and 90°F (32°C). It is recommended that you do not install the refrigerator near a heat source,
such as an oven or radiator.
*Space from a side wall required to open the door at 118° and open the drawers and trays inside the bottom compartments.
Electrical Requirements
Power Cord
Length
inches
mm
75
/
1920.9
5
8
Location Requirements
/
(95.3 mm) minimum space between the refrigerator and wall to allow the door
3
4
2
68" Full-Depth French Door Refrigerator
Water Lines*
*Water lines are not foamed in and are external.
1/2" (12.7 mm)
1/2" (12.7 mm) 3
Power Cord
Location
/
" (95.3 mm)
3
4
