Use CAT III rated leads or higher.
Press the SELECT button to select AC voltage, press and hold the button for
Frequency and Duty Cycle modes.
WARNING
Do not attempt to measure more than 1000V AC/1000V DC.
Features:
Frequency Measurement - Test lead input
Range
99.99Hz
999.9Hz
9.999kHz
99.99kHz
Sensitivity: 1.8Vrms
Duty Cycle - Test lead input
Range
1.0 to 99.0%
Frequency Measurement - Jaw input
Range
999.9Hz
1999Hz
Sensitivity: 5A
Frequency (Hz) / Duty Cycle
CAT IV
600V
600A
DL599
SELECT
BT
A
AUTO
V
30V
T
T
2
1
TEMP
SELECT
BT
Resolution
0.01Hz
0.1Hz
0.001kHz
0.01kHz
Accuracy
±(0.2% per kHz + 0.1% + 5 dgts)
Resolution
0.1Hz
1Hz
• Default = Auto Selection
• Press SELECT x1 =
• Press and hold ZERO x1 =
• Press and hold ZERO x2 =
• Press RANGE to select resolution
Accuracy
0.1% + 3dgts
Accuracy
0.5% + 5dgts
9
Overload Protection
1000V RMS
Overload Protection
1000V RMS
Overload Protection
600V RMS
