UEi Test Instruments DL599 Mode D'emploi page 17

TEMP
• Disconnect test lead probes from voltage source and meter.
• Move Input Jack Locks to "TEMP" setting.
• Use K-Type thermocouple temperature probes only.
• Stated accuracy does not account for thermocouple accuracy.
Features:
Range
-328˚F to 999˚F
(-200˚ to 999˚C)
1000˚F to 2462˚F
(1000˚ to 1350˚C)
The new DL599 clamp meter offers a digital field temperature calibration
procedure to make the process easier. Here are the steps.
1) Turn on DL599 while holding down RANGE button.
2) When 'FLD1' is displayed on LCD, press the ZERO button.
3) After entering Calibration mode, set dial to Temp position.
4) Confirm DL599 is in T1 mode.
5) After immersing T1 temperature probe in ice bath and temperature is
stable, press and hold ZERO button to save.
6) Press SELECT button to switch to T2 mode.
7) After immersing the T2 temperature probe in ice bath and temperature is
stable, press and hold ZERO button to save.
Temperature F˚/C˚
CAT IV
600V 600A
DL599
SELECT
BT
AUTO
30V
T
T
1
TEMP
SELECT
BT
Resolution
0.1°F (0.1˚C)
1°F (1˚C)
Temperature Calibration
Temp
• Default = T1
• Press SELECT x1 = T2
A
V
• Press SELECT x2 = T1 - T2
F
T
1
• Press and hold ZERO = F° or C°
• Readings show on lower display
2
Accuracy
±(1.0% +3.6˚F)
±(1.0% + 2.0˚C)
17
Overload Protection
30V RMS
