Specifications
Optional AUDIO input
Pin jack (2) –5dBu 47 kΩ or higher
Remote input
Serial remote
D-Sub 9-pin (1)
Parallel remote
Modular connector 8-pin (1)
Output
LINE A output connector
Y/C output 4-pin mini-DIN (1) Loop-through,
with 75 Ω automatic terminal
function
VIDEO output
BNC type (1) Loop-through, with
75 Ω automatic terminal function
AUDIO output
Pin jack (1) Loop-through
LINE B output connector
VIDEO output
BNC type (1) Loop-through, with
75 Ω automatic terminal function
AUDIO output
Pin jack (1) Loop-through
RGB/Component output connector
BNC type (3) RGB/Component output
Loop-through, with 75 Ω automatic
terminal function
AUDIO output
Pin jack (1) Loop-through
Externally synchronized output
BNC type (1) Loop-through, with 75 Ω
automatic terminal function
Remote output
Serial remote
D-Sub 9-pin (1) Loop-through
Built-in speaker output
0.8W (monaural)
.........................................................................................................................................................................................................
1) The aperture cannot be compensated for RGB input signals.
24
(US)
Video signal
Frequency response
575/50I, 480/60I component inputs
50 Hz to 10 MHz (0 dB/–3 dB)
Models other than the above or
RGB inputs
48 Hz to 24 MHz, (0 dB/ –3 dB)
1)
Aperture compensation
OFF: 0 dB
ON: 2 dB to 6 dB
575/50I, 480/60I inputs: 5 MHz
Input other than the above: 16 MHz
Picture performance
Normal scan 7% overscan of CRT effective
screen area
Underscan 5% underscan of CRT effective
screen area
Linearity PVM-14L5
H: 4% or less
V: 4% or less
PVM-20L5
H: 5% or less
V: 5% or less
Color temperature
D65, D93/USER (Adjustable color
temperature: 5000K to 10000K)
Convergence error
PVM-14L5
Center:
Peripheral: 0.5mm (
PVM-20L5
Center:
Peripheral: 0.7mm (
1
0.4mm ( / inch)
32
or less
1
/ inch)
32
or less
1
0.5mm ( / inch)
32
or less
1
/ inch)
32
or less
