ASSEMBLY INSTRUCTIONS
FAUCET AND DRAIN KIT
Begin the faucet assembly process with the sink unit in its upside down position.
Note: There are two additional holes marked on the underside of the sink, on either side of the
faucet hole. If the installer chooses to utilize a different faucet requiring two or three holes, those
holes may be cut out at the marked locations.
6.
With a pair of scissors, trim the cuff off one end
of the drain tube (L). Only trim in the valley of the
hose as shown by the dashed line.
7.
Connect the threaded adapter (N) to the trimmed
tube end. With the threads of the adapter facing
away from the trimmed end of the tube, push the
tube into the adapter.
8.
Thread the drain tube to the basin drain port.
6
L
N
