Transmitter Display
The display stays on for 30 minutes after
a button press. After 30 minutes with no
button presses, the display shuts off and
the transmitter goes into battery
conservation mode. Pressing any button
will cause the display to turn back on.
The various symbols you might see on
the display are explained below.
N N u u m m e e r r i i c c r r e e a a d d o o u u t t – Shows the chosen
stimulation level. Adjust with the
level up/level down (arrow) buttons. See
Set Stim Button Stimulation Level on
page EN-10.
These digits are also used to display
Dog1/Dog2 ID codes. A small 1 displays
to the left to indicate ID codes 150 to
199. A small 2 displays to the left to
indicate ID codes 200 to 250.
FieldPro-E Owner's Manual
Tone/ON-OFF
Stimulation
Stimulation
D D o o g g 1 1 / / D D o o g g 2 2 – Switch between
Level Up
Receiver collars by pressing the Dog
Select button. The symbol displayed is
Program
the dog receiver collar that responds to
Dog Select
Transmitter commands. See Two Dog
Systems on page EN-16.
Tone/ON-OFF
T T o o n n e e S S y y m m b b o o l l – This symbol appears
Stimulation
whenever Tone is part of the Stimulation
type selected. See Program the Stim
Stimulation
Level Up Type on page EN-10.
Dog Select
P P R R O O G G S S y y m m b b o o l l – This symbol appears
when the Transmitter is in programming
mode. See Programming the Transmitter
on page EN-10.
B B a a t t t t e e r r y y I I n n d d i i c c a a t t o o r r – The battery indicator
provides constant awareness of your
battery's power level. See Battery
Indicator on page EN-12 for more-
detailed information on the Battery
Indicator.
R R A A N N G G E E R R O O N N L L Y Y : :
B B a a c c k k l l i i g g h h t t – The Ranger Transmitter
features a backlit display. The Ranger
display backlight stays on for 5 seconds
after a button press.
M M o o m m e e n n t t a a r r y y – If the straight line is shown
(——), the stimulation is in Continuous
mode. If just the dot is shown (•),
stimulation is in Momentary mode. See
C/M on page EN-8.
C C o o n n t t i i n n u u o o u u s s o o r r
