Wiring Diagram; Important Warning - Bergstrom TRP Lite Instructions De Montage

LITE
Take care not to invert the polarities when connecting the unit to the battery. If this happens, the control
plate does not come on and the unit does not work.
Centrifugal
blower
Compressor
electronic
module

IMPORTANT WARNING!

Electronic
control
Original fuse box
Compressor
In power wiring
Connections
centre
25

Wiring diagram

Return
air sensor
Anti-freeze
sensor
Condenser
fan
Az Blue
N Black
R Red
V Green
B White
A Yellow
Na Orange
M Brown
