• To specify the trigger threshold value and motion sensor level
1. Move the highlighting to "Threshold".
2. Press 1(EDIT) to display a dialog box for specifying the trigger threshold value, which is
value that data needs to attain before sampling starts.
3. Input the value you want, and then press w.
4. Move the highlighting to "Level".
5. Press one of the function keys described below.
To select this type of level:
Below
Above
6. Press w to finalize Trigger Setup and return to the Advanced Setup menu (page
k Graph Setup
Use the Graph Setup screen to configure settings for the graph produced after sampling is
complete. You use the Sample Setup settings (page
• To configure Graph Setup settings
1. While the Advanced Setup menu (page
• This displays the Graph Setup screen.
2. To change the graph source data name display setting, use the f and c cursor keys
to move the highlighting to "Graph Func". Next, press one of the function keys described
below.
To specify this graph source data name display setting:
Display source data name
Hide source data name
• When the graph data is stored in a sample data memory file, the file name appears as
the source data name. When the graph data is stored in current data area, the channel
name appears.
Note
• For details about sample data memory and current data area, see "Using Sample Data
Memory" (page
ε
Using Advanced Setup
Currently selected item
ε
-33).
-17
ε
-11) to turn graphing on or off.
ε
-8) is on the display, press e(Graph).
Press this key:
1(Below)
2(Above)
ε
-8).
Graph Setup Screen
Press this key:
1(On)
2(Off)
