1. E-CON3 Overview
• From the Main Menu, enter the E-CON3 mode.
• The E-CON3 mode provides the functions listed below for simple and more efficient data
sampling using a Data Logger.
• 1(SET) ...............Displays a screen for setting up a Data Logger.
• 2(MEMORY) ......Displays a screen for saving Data Logger setup data under a file
• 3(PROGRAM) ....Performs program conversion.
• 4(START) ..........Starts data collection.
• 5(GRAPH) .........Graphs data sampled by a Data Logger, and provides tools for
• 6(HELP) .............Displays E-CON3 help.
• Pressing the K key (Setup Preview) or a cursor key while the E-CON3 main menu is on
the screen displays a preview dialog box that shows the contents of the setup in the current
setup memory area.
To close the preview dialog box, press J.
Note
• For details about setup data and the current setup memory area, see "Using Setup
Memory" (page
E-CON3 Overview
name.
• This function can be used to convert Data Logger setup data
configured using E-CON3 to a Data Logger control program that
can run on the fx-9860G Series/fx-CG10/fx-CG20/fx-CG20 AU.
• It also can be used to convert data to a program that can be run
on a CFX-9850 Series/fx-7400 Series calculator.
analyzing graphs. Graph Analysis tools include calculation of
periodic frequency, various types of regression, Fourier series
calculation, and more.
ε
-24).
ε
-1
E-CON3 Main Menu
