Quick Start
To attach the MultiSync
these instructions:
1. Turn off the power to your computer.
2. If necessary, install the display card into your system. For more information,
refer to the display card manual.
3. For the PC: Connect the 15-pin mini D-SUB of the captive signal cable to the
connector of the display card in your system (Figure A.1). Tighten all screws.
For the Mac: Connect the MultiSync FE
included) to the monitor connector on the Macintosh (Figure B.1). Attach the
15-pin mini D-SUB end of the captive signal cable to the MultiSync FE
Macintosh cable adapter on the computer (Figure B.1). Tighten all screws.
NOTE: To obtain the MultiSync FE
NEC-Mitsubishi Electronics Display of America, Inc. at (800) 820-1230.
4. For download information on the Windows
MultiSync monitor, refer to the References section of this User's Manual.
5. Connect one end of the power cord to the MultiSync FE
other end to the power outlet (Figure C.1).
6. Turn on the monitor (Figure D.1) and the computer.
NOTE: If you have any problems, please refer to the Troubleshooting section of
this User's Manual.
950+.wpc
FE
+
monitor to your system, follow
®
™
950
+ Macintosh cable adapter (not
950
+ Macintosh cable adapter, call
950
®
95/98/2000 INF file for your
Figure A.1
3
5
+
950
+ monitor and the
950
