Re-Name existing folders:
Touch existing folder or sub folder and touch
re-naming button. Existing folder name appears in
the text box and can be renamed. (Don't use special
characters) .Done button saves title.
Note: Pictures and videos are saved in a folder
created daily. To look at older recordings, select the
appropriate folder.
Back to operating elements
Live image streaming:
on
Reset damage catalog to presetting:
Note: Only the selected language will be restored
Back to live screen
Remove SD card safely:
Push button before removing SD card. Otherwise already stored data on
the SD card could be lost.
3.11 Replace the reel
Switch off ROCAM
 Installing ROCAM® 4 vertically. Front flap (6) must be closed here!
 Remove camera head (1) from the holder (10) and take the reel cable (4) carefully out of the
guide hook (11) (Only SL40: remove camera head).
 Position camera head (1) with cable (4) into the reel (8).
 Bayonet connection operated by a half turn, and pulling gently (hold counterpart).
 Use caution not to damage the connector!
off
®
4 before replacing the reel!
