Astralpool FLOC SYSTEM Manuel D'installation page 8

Impulses from water counter
Display
Advanced
Input Config
Pulse Mode
st
In the 1 level menu two new items will
appear; the first is for setting the number of
impulses per litre (1/1-999/999) and
consequently the system will dose
according to the values set.
Pulse
1/1
The second is for setting the number of
3 3
cc per m or the number of cc
Set Point Value
100
Frequency signal
Display
Advanced
Input Config
Frequency Mode
st
In the 1 level menu a new item will appear
for setting the number of impulses per
minute (1-200) and consequently the
system will dose according to the values
set
Freq. MAX
120
Priming
Priming is activated and deactivated using a side switch MOM position.
With the switch in the ON position, the system is on and ready for operation.
When the switch is on the OFF position, the pump goes on standby.
0000137718
p/l
Watermeter
Pulse sender
3
per litre
cc/m3
PLC Controller
p/min
+
230 Vac
Circulating pump
+
230 Vac
Circulating pump
rev. 1.0
Wiring
100...240 Vac
Wiring
100...240 Vac
6
