Electrical Connection:
Connect the power supply cable to the general power supply network and in parallel connect the Flow
connector to the recirculation pump if present on the system; the Flow inlet (230 Vac) is connected to the
Flow function, if enabled (ON) it allows the dosing to be activated when the system recirculation is present.
The programming menu can be accessed by simultaneously pressing the Enter and Esc keys for at least 5
seconds.
If a password other than 0000 is set, the system will ask for the password to access the programming menu.
Upon release of the keys the display will show:
Language
English
Set Point Value
100
Advanced
Access the submenu with the Enter key.
0000137718
+
230 Vac
Circulating pump
Display
%
Programming
EN, FR, DE, ES, IT
The dosing is set in % from 10 to 100%
With Advanced five submenus can be accessed:
Input Config
•
Set Point Unit
•
Statistics
•
Calibration
•
Flow
•
rev. 1.0
100...240 Vac
Settings
