TEST AND ADJUSTMENT
❒ Turn on the circuit breaker and light switch.
NOTE: Sensor has a 1
will detect motion. When first turned on or when
switching modes, wait 1
❒ Turn the SENSITIVITY (SENS) control to the mid position
and the ON-TIME control to the TEST position.
ON-TIME
10 5 1 TEST
Avoid aiming the control at:
• Objects that change temperature rapidly, such as heating
vents and air conditioners. These heat sources could
cause false triggering.
• Areas where pets or traffic may trigger the control.
• Nearby large, light-colored objects reflecting daylight
may trigger the shut-off feature. Do not point other lights at
the sensor.
5 ft.
Maximum Range
595-4991-06
Get user manuals:
See SafeManuals.com
1
/
minute warm up period before it
2
1
/
minutes.
2
SENS
MIN
Bottom of Sensor
60 ft.
Maximum
Coverage Angle
The detector is less sensitive to motion directly towards it and
more sensitive to across motion.
Motion
Least Sensitive
❒ Walk through the coverage area
noting where you are when the
lights turn on. Move the sensor
head up, down, or sideways to
change the coverage area.
MAX
❒ Adjust the SENSITIVITY as
needed. Too much sensitivity
may increase false triggering.
❒ Set the amount of TIME you
want the lights to stay on after
motion is detected (1, 5 or 10
minutes).
SPECIFICATIONS
Range . . . . . . . . . . . . . . Up to 60 feet (varies with sur-
Sensing Angle . . . . . . . . Up to 110°
Electrical Load . . . . . . . . Up to 500 Watts Maximum, Incan-
Power Requirements . . . 120 VAC, 60 Hz
110°
Operating Modes . . . . . . TEST, AUTO and MANUAL
Time Delay . . . . . . . . . . 1 , 5, 10 minutes
Sensitivity . . . . . . . . . . . Adjustable
DESA Specialty Products™ reserves the right to discontinue
products and to change specifications at any time without
incurring any obligation to incorporate new features in prod-
ucts previously sold.
3
Motion
Sensor
Most Sensitive
Aim Sensor Down
for Short Coverage
Aim Sensor Higher
for Long Coverage
rounding temperature).
descent
OVERRIDE
